FAR-2218-BB X-band, 12 kW, TR up FAR-2228-BB X-band, 25 kW, TR up FAR-2238S-BB S-band, 30 kW, TR up FAR-2238S-NXT-BB S-band, 250 W, TR up, Solid State
Enhanced dynamic range for a more complete EAV (Echo Average) Function!The EAV determination technology has been taken to the extreme by integrating wide-range dynamic image correlation techniques. Despite being a digital Radar, all echoes, from the weakest to the strongest, are displayed with richer shades.
Echo Average function with wide dynamic range
he addition of signal transformation technology, offering a wider dynamic range, provides a more stable image of a net and its floating line while suppressing noise and other unwanted echoes.
Automatic Clutter Elimination (ACE)
Quickly adjusts the Radar image with a single button press. When ACE is activated, the system automatically adjusts clutter reduction filters and gain control according to the sea and weather conditions.
Compared to the other two images on the right, the ACE function allows near-total suppression of noise and other unwanted echoes, while reinforcing those of targets and landmasses. In addition to this smart suppression capability, and unlike the sea clutter reduction, ACE also recognizes ghost and other false echoes, allowing them to be eliminated.
Sea clutter reduction provides a very sharp image. Nevertheless, this noise suppression considerably reduces the intensity of other important target and landmass echoes as well. Sea clutter reduction also does not allow the total suppression of unwanted false echoes.
When no noise reduction, all echoes, including echoes of waves or rain, are strongly reflected on the screen. The echoes of the other ships are mixed with this noise.
Fast Target Tracking™With Fast Target Tracking™, the FAR-22x8 series provides accurate tracking information; speed and course vectors are displayed in mere seconds, allowing operators to take action and avoid incidents at a very early stage.
InstantAccess Bar™ Provides immediate access to the functions you need
InstantAccess Bar™ contains shortcuts to menus for tasks (functions/actions) that are most frequently used by operators, providing quick access to the most critical functions.
The power to judge the situation at a glance with customizable TT and AIS displaysWhen these are previously set, AIS symbols can be displayed with different colors for each MMSI. It is also possible to change the name of the acquired targets and change their color or symbol.
*In the case of TT, it is possible to easily change the display by creating specific presets.
Solid State Radar model - NXT - specialized in target detection and maintainability (S-band only)FURUNO Solid State Radar technology generates clear echo images, which allows users to obtain a clear picture of the area around their vessel, including weaker echoes from small craft. Moreover, a fan-less Solid State antenna dramatically reduces maintenance costs for the magnetron and CPU fan.
Solid State Radar keeps almost same power ability as conventional magnetron radar according to low output power.
Power Amplifier Module of the Solid State transceiver
Well-designed controllers for stress-free operationThese control units are designed based on ergonomics. The RCU-031 Control Unit, specially designed for fisheries, incorporates all the main Chart Plotter functions and allows you to perform a variety of operations.
Refined antenna with high signal accuracy and excellent reliability
High image quality is achieved by the signal processor inside the antenna unit directly converting analog to digital signals before sending them to the main processor unit.
The new antenna shape suppresses aerodynamic drag and lightens the burden on the gear box. The gear box itself has also been redesigned. Decreased aerodynamic drag and DC brushless motor result in a very durable gear box that can be used for prolonged period of time.
